The Eurotherm 6100A and 6180A Series Data Recorders are a must-have for any business that values data integrity. Designed specifically to meet industry requirements for process records in pharmaceutical, aerospace, automotive, and food & beverage applications, these recorders are trusted by customers and auditors alike. With up to 48 input channels and a recording interval of just 125ms, the 6100 series is both self-contained and cost-effective. The 6180A offers unparalleled input accuracy and is freely configurable to suit your process requirements. Plus, with encrypted data transmission, data redundancy, and tamper-resistant binary data storage, these recorders are the perfect solution for secure, long-term records of your process.
Eurotherm 6100A Veradac Specifications
| Description | Information |
|---|---|
| PC Configuration | Yes |
| Batch Management | Yes |
| Auditor Features | Yes |
| Network Addressing | Boot P, DHCP, Fixed IP |
| Graphic Display | 6100A: 5.5″ / 6180A: 12.1″ |
| Protection | IP66 |
| Relay Outputs | Yes |
| Annotation | Yes |
| Contact Inputs | Yes |
| Communications | EtherNet/IP Server, Modbus TCP/RTU Master & Slave |
| Mathematics | Yes |
| Counters | Yes |
| Totalisers | Yes |
| Ethernet/FTP | Yes |
| Custom Screens | Yes |
| Remote Viewing | Yes |
| Recording Speed | 8Hz |
| Trend Speed | 8Hz |
| USB | 6100A: 3 USB / 6180A: 1 USB |
| Reports | 10 |
| Groups | 12 |
| Review of History (on screen) | Yes |
| AMS2750F | Yes |
| Inputs | 6100A: 18 / 6180A: 48 |
