Watlow 375 Strip Heaters

Watlow 375 Strip Heaters

Starting at: $49.00

Call 800-321-8007 or fill out our online form today to order this product or to speak with a Hi-Watt application specialist.

Categories: , , ,

Description

Watlow’s 375 strip heaters easily clamp onto equipment and provide uniform heating for dies and mold heating, packaging, tank and platen heating, autoclaves, ovens, and food warming applications. These heaters feature a thin layer of compacted insulation, allowing them to run at lower temperatures than conventional heaters.

Available Configurations:

High-Temperature, Finned, Mineral-Insulated

SKUs:
SGA1J6A
SGA1J12A

Download Spec Sheets

0/5 (0 Reviews)
  • Rugged Construction: Watlow’s 375 heaters are designed to last. They feature a nickel-chromium wire in the center of the heater, embedded in a thin layer of magnesium oxide or mineral insulation, and enclosed in aluminized steel, 430 stainless steel, or 304 stainless steel, depending on application needs.
  • Uniform Heating: Because the 375’s integrated nickel-chromium wire is in the middle of the unit, it radiates heat equally in all directions, maintains stable resistance across a wide temperature range, resists oxidation at high temperatures, and will provide consistent output along its entire length.
  • Versatile: Watlow’s 375 heaters are 100% customizable. Sheathing material, insulation type, design, and watt densities are configured based on your application needs.

Not sure if the 375 is the best option for your plant? Get in touch with our experts at Hi-Watt. We can provide product recommendations, along with installation assistance, on-site repairs and calibrations, and ongoing technical support.

Material Aluminized Steel, 304 Stainless Steel, or 430 Stainless Steel
Maximum Operating Temperature 595 degrees Celsius/1,100 degrees Fahrenheit (High-Temperature Configuration)
760 degrees Celsius/1,400 degrees Fahrenheit (Mineral-Insulated)
Maximum Watt Densities 15.5 W/cm2, 100 W/in2 (High-Temperature Configuration)
21.7/cm2, 140 W/in2 (Mineral-Insulated Configuration)
