Watlow's F4T controller. The interface is on, showing multiple temperature settings.

Watlow F4T

Starting at: $800.00

Call 800-321-8007 or fill out our online form today to order this product or to speak with a Hi-Watt application specialist.

Categories: , , ,

Description

The Watlow F4T is a powerful and versatile temperature and process controller designed for a wide range of industrial heating and thermal applications. The control distinguishes itself by integrating various control and monitoring functionalities into a single, user-friendly device, minimizing the need for multiple components and simplifying system design.

View Spec Sheet

0/5 (0 Reviews)
  • Intuitive Interface: The Watlow F4T requires minimal training. Operators can easily personalize profiles, alarms, inputs, and outputs using the 4.3” color-touch panel. The controller also supports multiple languages, including English, German, Spanish, Italian, French, Chinese, Korean, and Japanese.
  • Field Upgrades: These controllers can be configured to include up to four control loops and function block sets, and to support batch processing, data logging, and ramp and soak profiling.
  • Multiple Communication Options: F4T controllers can communicate via Ethernet/TCP, Ethernet ICP/Modbus TCP, or Modbus 485.
  • Responsive Alerts: The controller can be programmed to provide text or email alerts for input errors and conditional alerts.
  • Modular Design: The F4T comes with optional removable/field-pluggable I/P modules and offers up to 36 input/output quantities.
  • Backwards-Compatible With Older Watlow Controls: If you’re upgrading your controls, the F4T can easily replace discontinued F4S, F4D, or F4P controllers.
  • Auto-Tuning: The controller’s integrated TRU-TUNE® auto-tuning feature makes setup easier and reduces the need for separate, discrete components.
  • Backup Sensor: Should any unplanned shutdown occur that impacts the controller’s primary sensor, the controller will automatically switch to its SENSOR GUARD backup sensor.

The F4T controller is customized based on application requirements. If you’re not sure which configuration is best for your process, you can contact our application specialists. When you partner with Hi-Watt, you can expect responsive, same-day support, expert configuration and integration assistance, and ongoing technical support as needed.

Base Type Touch Screen
Data Logging Optional
Power Supply 100 to 240VAC or 24 to 28VAC or VDC
Connector Options Right angle or front screw (available options vary based on chosen power supply)
Profiles Up to 40
Communication Options Modbus® TCP or Ethernet/IP
Control Loops Up to 4
Cascade Loops Up to 2
Operating Temperature 0 to 122°F (-18 to 50°C)
USB Connector Type A
Number of USB Ports 2

Additional information

Weight 2 lbs
Dimensions 8 × 8 × 8 in
Interface

4.3" color operator interface
Field upgrades

Field upgradable features include:

• Up to 4 control loops
• Data logging
• Graphical Trend Chart
• Batch processing
• Ramp and Soak Profiling
• Function block sets
I/O module

Field removable I/O module
Limit modules

FM approved limit modules
Voltage

120v or 24v power options
Communication options

Communication options: Ethernet TCP, Ethernet IP/Modbus TCP, Modbus 485
